Product Details:
Payment & Shipping Terms:
|
| Condition: | New | Warranty: | 1 Year |
|---|---|---|---|
| Name: | Yuhong Pulse Dust Collector | Application: | Dust Collector |
| Color: | As Requirement | After-sales Service Provided: | Online Support |
| Type: | Pulse Dust Collector | Brand Name: | Yuhong |
| High Light: | industrial dust collector,pulse bag dust collector |
||
low price big filtration area pulse dust collector dust collecting machine
Working Principle:
Pulse bag Dust Collector is a dry dust filter facility filtering dust-contained gas with adoption of fiber-fabric filtering effect.
After such dust-contained gas enters bag dust collector, dusts with large particles and large proportions will drop down and fall into ash bucket due to with gravity effect.
After gases with fine dusts will pass through filter material, such dust will be retained for making them purified.
Production Introduction:
Pulse bag type dust collector is the introduction of our basic fule company of American technology, absorb the advantages of similar products of German technology, combined with the new high efficiency bag dust removal equipment research and development of the truth of our country, it sets the sectional reverse blow and blowing advantages of pulse bag type dust collector as a whole, overcomes the sectional reverse blow. Ash kinetic energy shortage, cleaning and filtering of pulse jet and the cylinder depression,expanded the scope of application of bag dust removal equipment.
Technical Parameter:
| Model | Filtration area(㎡) | Water concentration(g/m³) | Filtering wind speed(m/min) | Filtering air volume(m³/n) | Resistance(Pa) | Efficiency(%) | Dimensions(L*W*H)(mm) | Weight(kg) |
| MC36-Ⅱ | 27 | ＜15 | 0.8-1.2 | 3240-6480 | 1200-1500 | 99.5 | 1490*1678*3667 | 1485 |
| MC60-Ⅱ | 45 | ＜15 | 0.8-1.2 | 5400-10800 | 1200-1500 | 99.5 | 2290*1678*3667 | 1730 |
| MC72-Ⅱ | 54 | ＜15 | 0.8-1.2 | 6480-12960 | 1200-1500 | 99.5 | 2690*1678*3667 | 1950 |
| MC84-Ⅱ | 63 | ＜15 | 0.8-1.2 | 7560-15120 | 1200-1500 | 99.5 | 3090*1678*3667 | 2230 |
Our advantages:
1. The bag filter can dust filtration and air purification.
2. Integral pre-separation chamber, down flow inlet air pattern
3. Wide range of discharge options
4. The product has a good dust removal effect for larger proportions such as metal cutting, foundry sand and medium-gravity dust, such as cement and lighter-weight non-fibrous dust
