| Condition: | New | Color: | As Requirement |
|---|---|---|---|
| Key Word: | Vibrating Feeder | Production Name: | Vibrating Feeding Machine |
| Application: | Mining,construction,metally,quarry | Warranty: | 1 Year |
| High Light: | industrial vibrating feeder,disc sand feeder |
||
Yuhong new design vibrating feeder vibrating feed machinery from China
Product details
The electromagnetic feeder is applicable to products which is easy-broken, easy-separated and coated with flavouring, such as: baked food, snack food, potato chips, frozen food, peanut, confectionery that are with high requirement of convey system.No breakage of single machine. When comparing with common vibratory conveyor , the products’ breakage rate reduces about 50% and seasoning loss rate reduces 70%.Dynamic distributions of product at each convey point, multi-conveyor linkage for long distance transportation, multi-conveyor synchronization and in-phase transmission.
Technical parameters
| Model |
Productivity (t/h) |
Feeding size (mm) |
Supply Voltage (V) |
Matching control box model |
Weight (kg) |
| GZ3 | 25 | 75 | 220 | XKZ-5G2 | 217 |
| GZ4 | 50 | 100 | 220 | XKZ-20G2 | 412 |
| GZ6 | 150 | 200 | 380 | XKZ-20G3 | 1252 |
| GZ7 | 250 | 250 | 380 | XKZ-100G3 | 1920 |
| GZ8 | 400 | 300 | 380 | XKZ-100G3 | 3040 |
Features:
(1) the use of electrical control thyristor half wave rectifier circuit. Can be stepless adjustment of the feed rate, and can be used for automatic control in the production process, production automation.
(2) the electromagnetic vibration feeder no rotating parts, no need of lubrication, simple structure, convenient maintenance.
(3) the material in micro projectile motion, groove wear small,
(4) the electromagnetic vibration feeder trough alloy steel, can be used for conveying high temperature, wear and corrosion of materials etc.
The actual capacity is greater than or less than the calculated capacity, productivity conversion according to the actual material capacity.
Particle size of less than 1mm material conveying speed decreased and water content more than 10% wet sticky materials can not be normal delivery, material thickness exceeds a certain value, will hinder the normal feeding, recommended H= (1/3~1/4) slot.
For special requirements, special specifications, special design and manufacture can I plant.
