Vertical Ore Dressing Equipment Wet Pan Mill 1t/H Gold Grinding Mill

Vertical Ore Dressing Equipment Wet Pan Mill 1t/H Gold Grinding Mill
Vertical Ore Dressing Equipment Wet Pan Mill 1t/H Gold Grinding Mill Vertical Ore Dressing Equipment Wet Pan Mill 1t/H Gold Grinding Mill Vertical Ore Dressing Equipment Wet Pan Mill 1t/H Gold Grinding Mill Vertical Ore Dressing Equipment Wet Pan Mill 1t/H Gold Grinding Mill

Large Image :  Vertical Ore Dressing Equipment Wet Pan Mill 1t/H Gold Grinding Mill

Product Details:

Place of Origin: ZHENGZHOU
Brand Name: YUHONG
Certification: ISO,CE,BV,
Model Number: 1200B

Payment & Shipping Terms:

Minimum Order Quantity: 5sets
Price: Negotiation
Packaging Details: Standard package in wooden boxes or container.
Delivery Time: 10-12DAYS
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 60 SETS/MONTH
Detailed Product Description
Application: Gold Ore,silver Ore,iron Ore,lead Ore,zine Ore,antimony Ore Applicable Industries: Manufacturing Plant, Machinery Repair Shops, Energy & Mining
Model: 1200 Rollers Materials: ALLOY
Rollers Model: Outer Diameter 120 Cm Thickness 20 Cm Grinding Base Thickness: 12 Cm
Basin diameter: 230cm Basin thickness: 4mm
Motor Brand: Siemens Bearing Brand: Wangfangdian,ZWZ
High Light:

gold grinding machine

,

gold grinding mill

hot sale in sundan wet pan mill 1t/h vertical gold milling grinding machine stone grinder

Vertical Ore Dressing Equipment Wet Pan Mill 1t/H Gold Grinding Mill 0


Introduction

wet pan mill is mainly used for separation of gold, silver, lead, zinc, molybdenum, iron, copper, antimony, tungsten, tin and other minerals selected. With less investment, fast results, small footprint saving power, sturdiness and durability, ease of maintenance and high return on investment. It is the preferred production for alternative ball mill, is ideal for small and medium enterprises dressing.

Vertical Ore Dressing Equipment Wet Pan Mill 1t/H Gold Grinding Mill 1

Vertical Ore Dressing Equipment Wet Pan Mill 1t/H Gold Grinding Mill 2


Features

Wet pan mill mainly through the mixing of raw materials, rolling, crushing, rolling repeatedly to reach moisture equilibrium, the ratio of uniform, low gas content, to increase molding and molding quality, grind the material through the machine molding products. It has a high density, strength, and energy efficient, small investment ,low production cost,high output and always prised by users. Wet pan mill is used for iron ore tailings recovery process, not slag the loss,can make full use of effective resources.


Note:The model is named by the diameter of roller;the specification refers to diameter of roller*thickness of roller*thickness of grinding base*width of drinding base.


Technical Parameters

Model Specification Input size Rotate Speed Powder Weight
(mm) (r/min) (kw) (t)
1600A 1600×400×200×500±20mm <25mm 20-22 25KW 14.5
1500A 1500×350×200×460±20mm <25mm 20-22 22KW 13.5
1500B 1500×350×150×460±20mm <25mm 20-22 22KW 12.3
1500C 1500×300×150×420±20mm <25mm 20-22 22KW 11.3
1400A 1400×250×150×350±20mm <25mm 16-18 18.5kw 8.5
1400B 1400×250×150×350±20mm <25mm 21-23 18.5kw 8.5
1350A 1350×250×150×350±20mm <25mm 16-18 18.5kw 8
1350B 1350×250×150×350±20mm <25mm 21-23 18.5kw 8
1300A 1300×250×150×350±20mm <25mm 16-18 15kw 7.5
1300B 1300×250×150×350±20mm <25mm 21-23 15kw 7.5
1200A 1200×200×80×250±20mm <25mm 17-19 7.5kw 5.5
1200B 1200×200×80×250±20mm <25mm 23-25 7.5kw 5.5
1100A 1100×200×80×250±20mm <25mm 17-19 7.5kw 5
1100B 1100×200×80×250±20mm <25mm 23-25 7.5kw 5
1000 1000×200×80×250±20mm <25mm 13-15 5.5kw 4.5

;

Part views

Chrome material roller:Introduction of core technology ,wear-resisting improve>130%,the surface is smooth and without porosity

Vertical Ore Dressing Equipment Wet Pan Mill 1t/H Gold Grinding Mill 3
